Buy Teltonika | TSW101 | Automotive Ethernet Switch, 4+1 Port Gigabit Unmanaged Poe Switch, 802.3Af And At Compliant, 60W Power Budget Or 15W Per Port, 24V DC In, For Solar And Automotive Applications, No

Teltonika | TSW101 | Automotive Ethernet Switch, 4+1 Port Gigabit Unmanaged Poe Switch, 802.3Af And At Compliant, 60W Power Budget Or 15W Per Port, 24V DC In, For Solar And Automotive Applications, No

Part: 1441466
Model: TT.TSW101

$191.40

Availability

In Stock

#html-body [data-pb-style=KI7L7YM]{justify-content:flex-start;display:flex;flex-direction:column;background-position:left top;background-size:cover;background-repeat:no-repeat;background-attachment:scroll}Teltonika | TSW101 | Automotive Ethernet Switch, 4+1 port gigabit unmanaged POE Switch, 802.3af and at compliant, 60W power budget or 15W per port, 24V DC in, for solar and automotive applications, No PSUAutomotive PoE+ Switch The TSW101 is Teltonika Networks’ first automotive-dedicated unmanaged switch. Equipped with five Gigabit Ethernet ports, four of which support IEEE802.3af and IEEE802.3at PoE+ standards. With a wide range of supported power supply voltages (9-30 VDC), and its compact size it can slot into many automotive applications. Classified as a power source equipment (PSE), this device enables power supply centralization - providing up to 30 watts per single port and maximum output power of 60 watts. While also providing 10/100/1000 Mbps Ethernet ports for streamlined, high-bandwidth solutions. Ideal for providing both: in-vehicle power and an Ethernet data connection simultaneouslyFEATURES Ethernet 5 x RJ45 ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover PoE ports Port 1- 4 PoE standards 802.3af and 802.3at PoE Max Power per Port (at PSE) 30 W Total PoE Power Budget (at PSE) 60 W Maximum Ethernet cable length 100 m SPECIFICATIONS Bandwidth (Non-blocking) 10 Gbps Packet buffer 128 KB MAC address table size 2K entries Jumbo frame support 9216 bytes Connector 2-pin industrial DC power socket Input voltage range 9-30 VDC Input voltage range for PoE 9-30 VDC Power consumption Idle: 0.64 W / Max: 2.31 W / PoE Max: 60 W Ethernet 5 x RJ45 ports, 10/100/1000 Mbps Status LED’s 1 x Power LED, 10 x LAN status LED’s Power 1 x 2-pin industrial DC power socket Ground 1 x Grounding screw Casing material Aluminum housing Dimensions (W x H x D) 115 x 32 x 95 mm Weight 354 g Mounting DIN rail or wall mounting (additional kit needed), flat surface placement Operating temperature -40 °C to +75 °C Operating humidity 10 % to 90 % non-condensing Ingress Protection Rating IP30 Regulatory CE, REACH, RoHS, WEEE, CE, UKCA, FCC, IC, CB, RCM and E-Mark WHAT IS IN THE BOX TSW100 65 W PSU QSG (Quick Start Guide) Packaging box WARRANTY1-year limited warrantyWHY 4CABLING? Australia’s leading importer & wholesaler of 19” server racks, copper, et...
