MSI PRO DP10 13M-019BAU Barebone System - Socket BGA-1744 - 1 x Intel Core i7 13th Gen i7-1360P 2.20 GHz Dodeca-core (12 Core)

  • Part: 1463484
  • Model: PRO DP10 13M-019BAU
$849.20

Availability

In Stock

Resilient and Pioneering Spirit of Your Business

Your business should be empowered to stop at nothing while navigating your journey with the MSI Business & Productivity Series products.

Compact yet Powerful Business Center

Take a huge leap in performance and experience a boosted and faster rendering for the applications in this compact yet powerful business center that you work everyday.

The Way to Empower Your Business

Equips up to 13th Gen Intel® Core™ i7 processor with 12 cores and 16 threads, delivering computing capability and keeping you in the flow wherever you go.

Also, enjoy a more detailed, immersive viewing experience with Intel® Iris® Xe Graphics.

Bolt To The Next Power with Built-in Thunderbolt 4

Thunderbolt™ 4* brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all - delivering the fastest, most versatile connection to any dock, display, or data device & NAS.

Embracing a wide array of interface compatibilities so that you can edit, collaborate and share seamlessly

Up to 4 Displays with Thunderbolt

With one Thunderbolt, one DP-out, one HDMI™-out, and a VGA port (D-sub), PRO DP10 Series allows you to extend up to 4 monitors to pre-view your programming, E-commerce content & data at home or in the office.

Reversible Type-C With USB 3.2 Gen 2

When backup your projects at home, you can get all the performance benefits from USB 3.2 Gen 2, combined with the convenience of the reversible USB Type-C connector port.

Connect All of Your Devices with Wi-Fi 6E

Wi-Fi 6E puts more emphasis on transmission security and improves the signal between the interference problem can also be connected to more devices simultaneously, thereby meeting the trend of higher and higher data transmission bandwidth requirements with speeds up to 2.4Gbps.

Transfer Files & Work with 2.5G LAN

Connect and rapidly transfer data over a network with the high-bandwidth and low-latency 2.5Gbps Ethernet LAN.

  • General Information
    • Manufacturer
    • MSI
    • Manufacturer Website Address
    • http://au.msi.com
    • Brand Name
    • MSI
    • Product Series
    • PRO DP10 13M
    • Product Type
    • Barebone System
  • Warranty
    • Limited Warranty
    • 36 Month

  • Processor
    • Number of Processors Installed
    • 1
    • Processor Socket
    • Socket BGA-1744
    • Processor Manufacturer
    • Intel
    • Processor Type
    • Core i7
    • Processor Generation
    • 13th Gen
    • Processor Model
    • i7-1360P
    • Processor Core
    • Dodeca-core (12 Core)
    • Processor Speed
    • 2.20 GHz
    • Maximum Turbo Speed
    • 5 GHz
    • 64-bit Processing
    • Yes
  • Chipset
    • Chipset Manufacturer
    • Intel
  • Memory
    • Maximum Memory Supported
    • 64 GB
    • Memory Technology
    • DDR4 SDRAM
    • Memory Standard
    • DDR4-3200/PC4-25600
    • Total Number of Memory Slots
    • 2.0
  • Storage
    • Supported Storage Drive Interfaces
    • PCI Express
    • Supported Storage Drive Types
    • HDD
    • SSD
  • Display & Graphics
    • Graphics Controller Manufacturer
    • Intel
    • Graphics Controller Model
    • Iris Xe Graphics
    • Graphics Memory Technology
    • DDR4 SDRAM
    • Graphics Memory Accessibility
    • Shared
  • Network & Communication
    • Ethernet Technology
    • 2.5 Gigabit Ethernet
    • Wireless LAN
    • Yes
    • Wireless LAN Standard
    • IEEE 802.11ax
    • Bluetooth
    • Yes
    • Bluetooth Standard
    • Bluetooth 5.3
  • I/O Expansions
    • Number of Total Expansion Bays
    • 1
    • Number of 3.5" Bays
    • 0
    • Number of M.2 Interfaces
    • 2
  • Interfaces/Ports
    • HDMI
    • Yes
    • Total Number of USB Ports
    • 6
    • Number of USB 3.2 Gen 1 Ports
    • 5
    • USB Type-C (Front)
    • Yes
    • USB Type-C Detail
    • 1 x USB 3.2 Gen 2 Type C
    • Network (RJ-45)
    • Yes
    • DisplayPort
    • Yes
    • Number of VGA Ports
    • 1
    • Number of Thunderbolt 4 Ports
    • 1
    • VGA (Rear)
    • Yes
    • Number of DisplayPort Outputs (Rear)
    • 1
    • DisplayPort (Rear)
    • Yes
  • Operating System
    • Operating System Supported
    • Windows 11 Pro
  • Power Description
    • Maximum Power Supply Wattage
    • 120 W
  • Physical Characteristics
    • Color Family
    • Black
    • Product Color
    • Black
    • VESA Mount Standard
    • 75 x 75
    • Height
    • 179 mm
    • Width
    • 178.8 mm
    • Depth
    • 34.5 mm
    • Weight (Approximate)
    • 1.10 kg
  • Miscellaneous
    • Package Contents
      • PRO DP10 13M-019BAU Barebone System
      • 1 x AC Adapter
      • 1 x Power Cord
      • 2 x Quick Guide
      • 1x Wi-Fi Antenna
    • Features
    • Security Slot
    • Environmentally Friendly
    • Yes
    • Energy Efficiency Compliance
    • Energy-related Products Directive (ErP)
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
